Cone Crushers

Cone Crushers are manufactured and designed through absorbing the latest world advanced technology and gets to be world advanced level. It is widely used in the fields of metallurgy, construction, hydroelectric project, transport, chemical industries and building materials for crushing all sorts of hard and above medium hard ores and rocks. SMH Series Cone Crushers are of high performance, The optimized design of stroke, rotate speed and crushing cavity achives the effect of grinding, which increases the productivity and improves product shape.

Cone Crushers Feature and Advantage:

Cone Crushers possesses greater superiority than ordinary ones.

1. Larger crushing ratio, high production efficiency, high capacity and excellent product shape.

Crushing ratio and production efficiency is greatly improved as the increase of rated power and capacity with the effort of the combined higher rotate speed and reasonable stroke.

2.Rational construction, advanced crushing principle and technical data, reliable operation and low cost.

All components of crusher are protected by wear resistant materials, which reduces the maintenance cost and increace service life by almost 30%.

3.Lamination crushing principle, excellent product shape:

A prominent increase in fine material ratio and cubic product content, and massive decrease of elongated flaky particle are achieved through selective crushing of material, which results from the replacement of single-particle crushing chamber by special inter-particle-grinding crushing cavity.

4.Shorter down time

Sanme cone crushers adopt hydraulic bolt and overload protecting system, which release the impact force gently when uncrushable material is fed into the cavity and revert to original position after material discharged. The brand-new hydraulic cylinders can discharge the material when the machine stops with load. Hydraulic cone crusher has the advantages of safer, more convenient and shorter down time compared with traditional spring type cone crusher.

5.Thin oil lubricating: reliable, advanced and increases its service life.

Unique oil lubricating system increases the longevity of machine. Non-contact labyrinth sealing element is of high performance, which improves the reliability of dust resisting and fundamentally eliminates the problems caused by oil water mixture appeared in spring type cone crusher.

6.Various crushing cavities meet wide range of product size requirements.

By replacing the mantle and concave plate, the crushing cavity is adjustable, from standard coarse type to short-headed fine type, which meets large range of size requirements.

7.Easy maintenance and operation.

All parts of SMH Series Cone Crushers can be assembled, disassembled and repaired from the top and side part, including the fixed cone and movable cone. It is no need to disassemble and install the frame, and fasten bolts, so SMH cone crusher is much more convenient and fast for replacing liner plates. The crusher production efficiency will be much better by using the hydraulic motor.

8.Padding free in mantle and concave changing.

SANME hydraulic cone crushers adopt new fixing method of mantle and concave, which are padding free and less time consuming.




Cone Crushers Main Technical Data:

Model	Max Feeding Size(mm)	Discharge Range(mm)	Moter Power(kw)	Capacity(t/h) -- open circuit,closed discharge(mm)
				9	13	16	19	22	26	32	38	51	63	76	89
SMH120C	160	22~32	75-90					120	130	150
SMH120M	130	13~26	75-90		65	85	100	120	130
SMH120F	50	9~19	75-90	40	60	80	90	110
SMH180C	180	22~32	132-160					185	195	215
SMH180M	140	13~32	132-160		90	115	135	160	180	200
SMH180F	60	9~22	132-160	60	80	100	120	140
SMH250C	220	26~51	160-220						250	290	340	395
SMH250M	150	16~38	160-220			125	140	165	220	275	330
SMH250F	80	9~22	160-220	70	90	115	130	150
SMH350EC	315	38~64	250-280								555	649	766
SMH350C	230	26~64	250-280						366	430	468	629	657
SMH350M	205	22~52	250-280					266	299	348	393	451
SMH350F	180	16~38	250-280			188	212	234	267	305	337
SMH550EC	450	38~89	400								890	1179	1380	1475	1566
SMH550C	350	31~76	400							800	850	1100	1288	1398
SMH550M	320	25~63	400						612	735	815	990	1137
SMH550F	268	19~52	400				376	412	500	620	725	867

Technical Date of SMH Series Short Head Hydraulic Cone Crushers:

Model	Max Feeding Size(mm)	Discharge Range(mm)	Moter Power(kw)	Capacity(t/h) -- open circuit,closed discharge(mm)
				3	5	6	9	13	16	19	22	26	32	38
SMH120DC	70	6-9	75-90			59	68	96	110	130
SMH120DM	51	5-16	75-90		45	59	68	96	110
SMH120DF	35	3-13	75-90	30	45	50	65	90
SMH180DC	70	6-9	75-90			72	90	108	131	158
SMH180DM	51	5-16	75-90		68	76	95	118	145
SMH180DF	35	3-13	75-90		70	82	95	120
SMH250DC	89	9-22	160-220				100	120	145	175	210
SMH250DM	70	6-16	160-220			82	105	130	160
SMH250DF	54	5-16	160-220		80	90	110	135	160
SMH350DEC	133	13-25	250-280					280	310	340	370	390
SMH350DC	133	10-25	250-280				210	280	310	340	370	390
SMH350DM	89	6-19	250-280			130	168	215	260	290
SMH350DF	70	6-13	250-280			130	168	215
SMH550DEC	203	16-25	400						510	600	630	680	720	750
SMH550DC	178	13-25	400					455	488	552	600	620	698
SMH550DM	133	10-19	400				355	420	460	530	545	580
SMH550DF	105	6-16	400			220	310	375	428	482	497
