Sand Washing Machine is mainly used for washing and dehydrating sand stones for constructions. It is the highly effective equipment that is matched with sand maker.Sand washing machine is used for removing the dust in sand. It aims at improving the quality of sand. The materials include the requiring gravel in building-site, gravel factories, hydropower station and concrete dam site, post and electric pole factory, glass factory's quartz sand and refilling pressure sand, etc.
Sand washing machine is sand washing plant, mainly used for removing dust in the ore. Impurity and dust are removed in the artificial sand production process. According to its shape, sand washing machine can be divided into spiral sand washing machine and bucket sand washer.
Sand washing plant, also Sand washing machine is widely used in the construction site, sand stone factory, the construction site of concrete dam of a hydropower station, concrete pre-cast parts factory, oil-well refilling and other industries.
As a professional Sand washing machine supplier, our sand washing equipment is of high efficiency. Our Sand washing machine has adopted advanced technology and combined with the real situation of sand line. The mineral sand washer has simple structure and it is easy to maintain. And also has the characteristics of durability, saving water and no pollution.
Our sand washing machine is widely used in building-site, gravel factories, hydropower station and concrete dam site, post and electric pole factory, casting-70 sand, glass factory's quartz sand and dehydrating for pressure sand used in oil well's refill.
Feed size: ≤10mm
Capacity: 20-180t/h
Suitable raw
material: medium and coarse material
Applications: road construction, hydropower and building construction.
Spiral sand washers are characteristics of reasonable structure, easy maintenance, great capacity, low consumption and high purity. The machine is equipped with creative sealing structure, oil-bathed airproof driving system, which is of high efficiency, reliable, effectiveness of washing and dehydration.
1. The sand washer has high washing cleanliness and causes no pollution or little sand loss during the washing process.
2. Designed with rational structure, novel seal structure, totally enclosed oil bath type gearing and adjustable overflow weir plate.
3. Very little medium sand, fine sand and stone powder loss during the washing process. The grading and fineness modulus of building sand washed are all up to industrial standard.
4. Handling capacity is great and power consumption is low.
5. The sand washer saves water resources and causes no pollution. It is quite durable.
6. Easy to maintain and convenient to operate.
| Model | Diameters of The Wheel Buckert(mm) | Speed of Rotor(r/min) | Feed Opening Size(mm) | Capacity(t/h) | Motor Power(kw) | Overall Dimensions(L×W×H)(mm) | Weight(kg) | ||
| XS2600(I) | 2600 | 2.5 | ≤10 | 20-50 | 5.5 | 3515×2070×2672 | 2500 | ||
| XS2600 (II) | 2600 | 2.5 | ≤10 | 30-70 | 5.5 | 3515×2270×2672 | 2900 | ||
| XS2800 | 2800 | 1.2 | ≤10 | 50-100 | 7.5 | 3900×3300×2990 | 3980 | ||
| XS3200 | 3200 | 1 | ≤10 | 80-120 | 11 | 3965×4440×3410 | 6560 | ||
| XS3600 | 3600 | 1 | ≤10 | 120-180 | 15 | 4355×4505×3810 | 9430 | ||
